Tlačiareň štítkov elio XP-TT426B

Termotransferová tlačiareň štítkov





Printer Model XP-TT426B
Resolution 203 DPI
Printing method             Thermal Transfer / Direct Thermal
Max.print speed             127 mm (5”) / s
Max.print width             108 mm (4.25”)
Max.print length             1778 mm (70”)
Media type             Continuous, gap, black mark, fan-fold and punched hole
Media width             25.4-118mm (1.0”~4.6”)
Media thickness             0.06~0.254 mm(2.36~10mil)
Label length             10 ~ 1778 mm(0.39" ~ 70" )
Label roll capacity             127 mm (5”) external diameter
Ribbon & Ribbon width 300m, Max roll diameter 67mm, Core Diameter: 1”, 40mm~110mm (1”~4.3”)
Enclosure ABS plastic
Dimension 299 x 235  x 198.3 mm
Weight 2.57 kg
Processor             32 bit RISC CPU
Memory 5MB Flash Memory
8MB SDRAM
Micro TF card reader for Flash memory expansion, up to 4GB
Interface USB 2.0(Standard)/ Serial(Optional)/ WIFI(Optional)/ Bluetooth(Optional) / Ethernet(Optional)
Power supply Built-in power supply with auto switching
Input:AC 100-240V,1.8A, 50-60Hz
Output:DC 24V, 2.5A, 60W
Operation switch, button, LED 1 power switch, 1 feed button, 1 LED (3 colors: red, purple, blue)
Sensors type Transmissive gap sensor ( position adjustable)
Black mark reflective sensor ( position adjustable)
Ribbon end sensor
Print head open sensor
Real time clock Standard
Internal fonts             8 alpha-numeric bitmap fonts
Windows fonts are downloadable from software.
Barcodes


1D bar code: Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11
2D bar code: PDF-417, Maxicode, DataMatrix, QR code, Aztec
Graphics BIMAP, BMP, PCX(Max. 256 colors)
Font and barcode rotation 0°, 90°, 180°, 270°
Printer language TSPL, EPL, ZPL, DPL
Environment condition Operation temperature:5℃-40℃(41℉-104℉),Humidity (non-condensing): 25%-85%
Storage:-40℃-60℃(-40℃-140℃), Humidity (non-condensing): 10%-90%
Safety regulation FCC, CE, CCC, CB
Environmental concern RoHS
Standard accessories ①Windows labeling software,driver and user manual Cd  ②quick start guide  ③USB cable ④power cord    ⑤external switching power adapter  ⑥label spindle, fixing tab x 2       ⑦Ribbon spindle x 2   ⑧Ribbon paper core
Factory Options ①Ethernet(10/100 Mbps);②RS-232C(2400-115200 bps)
Dealer options ① Label peel-off module; ② Cutter module(full/partial),paper thickness 0.06-0.19mm,500000 cuts;0.20-0.25mm, 200000 cuts
User options

① External roll mount (1”core)       ② Bluetooth module(RS-232C interface)

③ WIFI module                                 ④ external roll mount board
